ESP32 Distance Sensor

Welcome to the ESP32 Distance Sensor project!

This IoT device measures distance using an ultrasonic sensor and displays results on a beautiful LED strip. Perfect for garage parking assistance, learning embedded systems, or hands-on workshops.

🎯 What Is This Project?

An ESP32-powered distance sensor that helps you park your car perfectly every time! It combines:

  • HC-SR04 Ultrasonic Sensor - Measures distance with millimeter precision

  • WS2812 LED Strip - 40 individually addressable LEDs for visual feedback

  • ESP32 Microcontroller - WiFi-enabled brain running FreeRTOS

  • Web Interface - Mobile-responsive configuration and monitoring

The Story Behind It: Born from frustration after one too many bumper-meets-wall incidents in the garage. Sometimes the best projects solve real problems! 🚗

🚀 Quick Start

New to the project? Start here:

  1. 📖 Understand the Project - Read the Project Introduction for context and motivation

  2. 🛠️ Check Hardware Needs - See Hardware Specifications for components and pin configuration

  3. ⚡ Build and Run - Follow Quick Start Guide to get started in minutes

No hardware? Try QEMU emulation! Full simulator with network support included.

✨ Key Features

Hardware & Sensors:

  • Real-time distance measurement (HC-SR04, 10Hz update rate)

  • Visual LED display (40× WS2812, position + color feedback)

  • Configurable range (default: 10cm-50cm mapped to LED strip)

Connectivity & Interface:

  • WiFi connectivity (AP and STA modes)

  • Captive portal for easy setup

  • HTTP web interface (mobile-responsive)

  • Configuration persistence (NVS storage)

Development & Testing:

  • GitHub Codespaces - Zero-setup cloud development

  • DevContainer - Alternative setup for your local enviroment (requires Docker)

  • QEMU Emulation - Hardware-optional development with full network stack

  • GDB Debugging - Breakpoint debugging in emulator

  • Professional Documentation - Sphinx-Needs requirements engineering

Software Architecture:

  • Component-based design (modular, maintainable)

  • FreeRTOS task management (real-time operation)

  • ESP-IDF v5.4.1 (official framework)

  • Optimized for embedded devices (4MB flash configuration, fix point integer…)

📚 Documentation Navigation

Getting Started:

Requirements & Design:

Development:

Workshop:

🎓 Who Is This For?

  • Makers & Tinkerers - Build a practical IoT device with real-world applications

  • Students & Learners - Hands-on introduction to embedded systems development

  • Workshop Participants - Guided learning with professional engineering practices

  • Embedded Developers - Reference implementation of ESP-IDF best practices

💡 What You’ll Learn

  • Embedded Systems - FreeRTOS, hardware interfaces, memory management

  • IoT Connectivity - WiFi, HTTP servers, network protocols

  • Software Engineering - Component architecture, requirements engineering, testing

  • Modern Tools - GitHub Codespaces, QEMU, GDB debugging

  • Vibe-coding embedded - AI-assisted coding with GitHub Copilot, Coding Agent and using prompt templates

🛠️ Built With

  • ESP-IDF v5.4.1 - Official Espressif IoT Development Framework

  • FreeRTOS - Real-time operating system

  • Sphinx-Needs - Professional requirements engineering

  • QEMU - Full ESP32 hardware emulation

  • GitHub Codespaces - Cloud-based development environment

Based on: esp32-template - Professional ESP32 project template with lots of features! - check it out

All Requirements Overview

US_DEV_1: Modular Firmware Extensibility (implemented) [developer; firmware; extensibility]
US_DEV_2: Traceable Supporting Documentation (implemented) [developer; documentation; traceability]
US_DISPLAY_1: Visual Distance Feedback for Parking (approved) [display; sensor; garage-user]
US_RELIABLE_1: Appliance Reliability - Just Works on Power (approved) [reliability; startup; garage-user]
US_SETUP_1: Device Setup via Web Interface (approved) [setup; wifi; web; maker]
REQ_CFG_JSON_1: JSON Schema as Configuration Source of Truth (implemented) [config; schema; architecture]
REQ_CFG_JSON_2: Parameter Grouping for UI Organization (implemented) [config; ui; schema]
REQ_CFG_JSON_3: Parameter Type System (implemented) [config; types]
REQ_CFG_JSON_4: Build-Time Factory Defaults Generation (implemented) [config; build; code-generation]
REQ_CFG_JSON_5: No Runtime JSON Parsing in C Code (implemented) [config; performance; memory]
REQ_CFG_JSON_6: Key-Based NVS Storage (implemented) [config; storage; nvs]
REQ_CFG_JSON_7: Type-Safe Configuration API (implemented) [config; api; type-safety]
REQ_CFG_JSON_8: Persistent Configuration Storage (implemented) [config; storage; nvs]
REQ_CFG_JSON_9: Factory Reset Capability (implemented) [config; reset]
REQ_CFG_JSON_10: Web Interface Integration Support (approved) [config; integration]
REQ_CFG_JSON_11: NVS Error Graceful Handling (implemented) [config; error-handling; reliability]
REQ_CFG_JSON_12: Configuration Initialization on Boot (implemented) [config; boot]
REQ_CFG_JSON_13: Simple Process to Add Configuration Fields (implemented) [config; extensibility; developer-experience]
REQ_CFG_JSON_14: Type Safety via Optional Static Validation (implemented) [config; validation; developer-experience]
REQ_CFG_JSON_15: Configuration Schema Versioning and Migration (open) [config; versioning; migration; future]
REQ_DEV_DOC_1: Supporting Documentation Traceability (implemented) [developer; documentation; traceability]
REQ_DEV_README_1: README Content Scope (implemented) [developer; documentation; readme]
REQ_DEV_OV_INDEX_1: Overview Index Content (implemented) [developer; documentation; overview]
REQ_DEV_OV_HW_1: Hardware Specifications Content (implemented) [developer; documentation; hardware]
REQ_DEV_OV_QS_1: Quick Start Content (implemented) [developer; documentation; quickstart]
REQ_DEV_GUIDE_QEMU_1: QEMU Emulator Guide Content (implemented) [developer; documentation; qemu]
REQ_DEV_GUIDE_MODES_1: Switching Dev Modes Guide Content (implemented) [developer; documentation; devmodes]
REQ_DEV_GUIDE_DEBUG_1: Debugging Guide Content (implemented) [developer; documentation; debugging]
REQ_DEV_GUIDE_FLASH_1: Web Flasher Guide Content (implemented) [developer; documentation; flasher]
REQ_DEV_ENV_1: Supported Development Environments (implemented) [developer; devcontainer; codespaces]
REQ_DEV_LIMITS_1: Known Limitations Documentation (implemented) [developer; limitations; known-issues]
REQ_DSP_1: Hardware Platform (approved) [display; hardware; integration]
REQ_DSP_2: Configuration Integration (approved) [display; configuration; integration]
REQ_DSP_3: Core Visualization Concept (approved) [display; ux; visualization]
REQ_DSP_4: Below Minimum Distance Warning (approved) [display; ux; safety]
REQ_DSP_5: Out of Range Display (approved) [display; ux; error-handling]
REQ_SNS_1: Component Initialization (approved) [sensor; initialization; gpio]
REQ_SNS_2: Trigger Pulse Generation (approved) [sensor; trigger; timing]
REQ_SNS_3: Real-Time Timestamp Capture (approved) [sensor; isr; timing; real-time]
REQ_SNS_4: Measurement Processing (approved) [sensor; processing; filtering]
REQ_SNS_5: Blocking API Access (approved) [sensor; api; synchronization]
REQ_SNS_6: Task Lifecycle Management (approved) [sensor; lifecycle; freertos]
REQ_SNS_7: Health Monitoring (approved) [sensor; monitoring; diagnostics]
REQ_SNS_8: Real-Time ISR Constraints (approved) [sensor; performance; real-time; isr]
REQ_SNS_9: Memory Resource Limits (approved) [sensor; memory; resource]
REQ_SNS_10: Timing and Performance (approved) [sensor; performance; timing]
REQ_SNS_11: Accuracy and Calibration (approved) [sensor; accuracy; calibration]
REQ_SNS_12: Timeout Error Handling (approved) [sensor; error-handling; timeout]
REQ_SNS_13: Range Validation (approved) [sensor; error-handling; validation]
REQ_SNS_14: Queue Overflow Management (approved) [sensor; error-handling; queue]
REQ_LED_1: WS2812 LED Strip Support (approved) [led; hardware; ws2812]
REQ_LED_2: Individual Pixel Control (approved) [led; control; api]
REQ_LED_3: Configurable LED Count (approved) [led; configuration; flexibility]
REQ_LED_4: Accurate Color Display (approved) [led; quality; color-accuracy]
REQ_LED_5: LED State Read API (approved) [led; api; monitoring; web-interface]
REQ_NETIF_TUNNEL_1: QEMU UART Network Bridge (approved) [emulation; network; qemu; uart]
REQ_NETIF_TUNNEL_2: Packet Encapsulation (approved) [emulation; protocol]
REQ_NETIF_TUNNEL_3: Host-Side Bridge Script (approved) [emulation; tooling; host]
REQ_NETIF_TUNNEL_4: DHCP Client Support (approved) [emulation; network; dhcp]
REQ_NETIF_TUNNEL_5: Conditional Compilation (approved) [emulation; build]
REQ_NETIF_TUNNEL_NF_1: Tunnel Throughput (approved) [emulation; performance]
REQ_NETIF_TUNNEL_NF_2: Packet Loss Handling (approved) [emulation; reliability]
REQ_NETIF_TUNNEL_DOC_1: Emulation Setup Documentation (approved) [emulation; documentation]
REQ_STARTUP_1: LED Controller Initialization (approved) [startup; initialization; led]
REQ_STARTUP_2: Visual Boot Sequence (approved) [startup; ux; validation]
REQ_STARTUP_3: Timing Performance (approved) [startup; performance; timing]
REQ_SYS_1: Garage Parking Assistance System (approved) [system; parking; garage]
REQ_SYS_HW_1: ESP32 Hardware Platform (approved) [hardware; platform]
REQ_SYS_NET_1: WiFi Connectivity (approved) [network; wifi]
REQ_SYS_WEB_1: Web-based Configuration (approved) [web; configuration]
REQ_SYS_CFG_1: Non-volatile Configuration Storage (approved) [storage; nvs; configuration]
REQ_SYS_ARCH_1: Component-based Architecture (approved) [architecture; modularity]
REQ_SYS_REL_1: Error Handling and Recovery (approved) [reliability; error-handling]
REQ_SYS_PERF_1: Memory Management (approved) [performance; memory]
REQ_SYS_SIM_1: Emulator Support (approved) [emulator; qemu; testing]
REQ_SYS_SIM_2: Emulator Network Connectivity (approved) [emulator; qemu; network; development]
REQ_SYS_SEC_1: HTTPS Support (open) [security; https; future]
REQ_SYS_TIME_1: System Time and NTP Support (open) [time; ntp; future]
REQ_WEB_1: Real-time Status Display (approved) [web; ui; monitoring]
REQ_WEB_2: Configuration Interface (approved) [web; ui; configuration]
REQ_WEB_3: WiFi Setup Interface (approved) [web; wifi; network]
REQ_WEB_CONF_1: Configuration REST API (approved) [web; api; config]
REQ_WEB_SCHEMA_1: Schema-Driven Configuration Form (approved) [web; ui; config]
REQ_WEB_4: Web Interface Navigation (approved) [web; ui; navigation]
REQ_WEB_5: HTTP Server Concurrency (approved) [web; performance]
REQ_WEB_LED_1: LED State API Endpoint (approved) [web; api; led; visualization]
REQ_WEB_NF_1: Web UI Responsiveness (approved) [web; performance; ux]
REQ_WEB_NF_2: Mobile-First Design (approved) [web; ui; mobile]
SPEC_CFG_JSON_ARCH_1: JSON Schema-Driven Architecture (draft) [architecture; config; json-schema]
SPEC_CFG_JSON_SOURCE_1: JSON Schema as Single Source of Truth (approved) [architecture; schema; design-pattern]
SPEC_CFG_JSON_SCHEMA_1: Configuration Schema Structure (approved) [data-structure; schema]
SPEC_CFG_JSON_CODEGEN_1: Factory Reset via Bulk JSON Update (approved) [build-process; code-generation; factory-reset]
SPEC_CFG_JSON_STORAGE_1: NVS Storage Format (approved) [storage; nvs]
SPEC_CFG_JSON_API_1: Type-Safe Configuration API (approved) [api; interface; c-api]
SPEC_CFG_JSON_UI_1: JSON Schema for UI Generation (approved) [web; ui; javascript]
SPEC_CFG_JSON_BULK_1: Bulk JSON Configuration API (approved) [api; json; bulk-operations]
SPEC_CFG_JSON_EXTEND_1: Adding New Configuration Fields (approved) [development; guide; extensibility]
SPEC_CFG_JSON_TYPESAFETY_1: Type Safety Without Code Generation (approved) [type-safety; best-practices]
SPEC_CFG_WEB_ARCH_1: Configuration Webpage Architecture (implemented) [frontend; javascript; ui]
SPEC_CFG_WEB_FLOW_1: Configuration Data Flow (implemented) [data-flow; json; api]
SPEC_CFG_WEB_FORM_1: Dynamic Form Generation from Schema (implemented) [form-generation; schema; javascript]
SPEC_CFG_WEB_MAPPING_1: JSON Array to Form Field Mapping (implemented) [data-mapping; json; form]
SPEC_CFG_WEB_STATE_1: UI State Management (implemented) [ui-state; javascript]
SPEC_CFG_WEB_COUNTDOWN_1: Device Reset Countdown Interface (implemented) [ui; countdown; reset]
SPEC_CFG_WEB_ERROR_1: Error Handling and User Feedback (implemented) [error-handling; feedback]
SPEC_CFG_WEB_INIT_1: Complete Page Initialization Flow (implemented) [initialization; lifecycle]
SPEC_DEV_ENV_OPTIONS: Supported Development Environments — Options (implemented) [developer; devcontainer; codespaces]
SPEC_DEV_ENV_USAGE: Supported Development Environments — Setup Steps (implemented) [developer; devcontainer; codespaces]
SPEC_DEV_README_INTRO: README Introduction and Project Link (implemented) [developer; documentation; readme]
SPEC_DEV_README_META: README Metadata Section (implemented) [developer; documentation; readme]
SPEC_DEV_OV_INDEX_WHAT: Overview Index — Project Description (implemented) [developer; documentation; overview]
SPEC_DEV_OV_INDEX_WHO: Overview Index — Audience Section (implemented) [developer; documentation; overview]
SPEC_DEV_OV_INDEX_NAV: Overview Index — Navigation Section (implemented) [developer; documentation; overview]
SPEC_DEV_OV_HW_COMPONENTS: Hardware Components Listing (implemented) [developer; documentation; hardware]
SPEC_DEV_OV_HW_PINS: Hardware Pin Assignment Table (implemented) [developer; documentation; hardware]
SPEC_DEV_OV_QS_QEMU: Quick Start — QEMU Path (implemented) [developer; documentation; quickstart; qemu]
SPEC_DEV_OV_QS_HW: Quick Start — Hardware Path (implemented) [developer; documentation; quickstart; hardware]
SPEC_DEV_GUIDE_QEMU_START: QEMU Guide — Starting QEMU (implemented) [developer; documentation; qemu]
SPEC_DEV_GUIDE_QEMU_WEB: QEMU Guide — Accessing the Web Interface (implemented) [developer; documentation; qemu]
SPEC_DEV_GUIDE_QEMU_STOP: QEMU Guide — Stopping QEMU (implemented) [developer; documentation; qemu]
SPEC_DEV_GUIDE_MODES_HOW: Dev Modes Guide — How to Switch (implemented) [developer; documentation; devmodes]
SPEC_DEV_GUIDE_MODES_DIFF: Dev Modes Guide — What Changes Between Modes (implemented) [developer; documentation; devmodes]
SPEC_DEV_GUIDE_DEBUG_START: Debugging Guide — Quick Start in QEMU (implemented) [developer; documentation; debugging]
SPEC_DEV_GUIDE_DEBUG_FEATURES: Debugging Guide — Debugging Features (implemented) [developer; documentation; debugging]
SPEC_DEV_GUIDE_FLASH_OVERVIEW: Web Flasher Guide — Overview and Browser Requirements (implemented) [developer; documentation; flasher]
SPEC_DEV_GUIDE_FLASH_STEPS: Web Flasher Guide — Flash Procedure (implemented) [developer; documentation; flasher]
SPEC_DSP_OVERVIEW_1: WS2812 Hardware Integration (approved) [display; hardware; integration]
SPEC_DSP_ARCH_1: Task-Based Architecture (approved) [display; freertos; task]
SPEC_DSP_ARCH_2: Configuration Integration (approved) [display; configuration]
SPEC_DSP_ALGO_1: Distance-to-Visual Mapping Algorithm (approved) [display; algorithm; mapping]
SPEC_DSP_ALGO_3: Embedded Arithmetic Architecture (approved) [display; performance; arithmetic]
SPEC_DSP_API_1: Public Display API (approved) [display; api; interface]
SPEC_SNS_ARCH_1: Dual-Queue Real-Time Architecture (approved) [sensor; architecture; real-time]
SPEC_SNS_ARCH_2: GPIO Interface Design (approved) [sensor; gpio; hardware]
SPEC_SNS_ISR_1: Interrupt Service Routine Design (approved) [sensor; isr; real-time]
SPEC_SNS_TASK_1: Sensor Task Design (approved) [sensor; freertos; task]
SPEC_SNS_ALGO_1: Distance Calculation Algorithm (approved) [sensor; algorithm; calibration]
SPEC_SNS_ALGO_2: EMA Smoothing Filter Design (approved) [sensor; algorithm; filtering]
SPEC_SNS_API_1: Public API Design (approved) [sensor; api; interface]
SPEC_SNS_ERR_1: Error Handling Design (approved) [sensor; error-handling; robustness]
SPEC_SNS_SIM_1: Distance Sensor Simulator Design (approved) [sensor; simulator; qemu]
SPEC_ARCH_LAYERS_1: ESP32 Distance Sensor Layered Architecture (approved) [architecture; layering]
SPEC_ARCH_CONFIG_1: Configuration Manager Component Design (approved) [component; config]
SPEC_ARCH_WEB_1: Web Server Component Design (approved) [component; web; network]
SPEC_ARCH_CERT_1: Certificate Handler Component Design (draft) [component; security]
SPEC_ARCH_NETIF_1: Network Tunnel Component Design (approved) [component; qemu; network]
SPEC_ARCH_COMM_1: Component Communication Pattern (approved) [dataflow; communication]
SPEC_ARCH_CONFIG_FLOW_1: Configuration Data Flow (approved) [dataflow; config]
SPEC_ARCH_WIFI_1: WiFi Manager Design Details (approved) [network; wifi]
SPEC_ARCH_HTTP_1: HTTP Server Architecture Details (approved) [network; http; web]
SPEC_ARCH_QEMU_1: QEMU Hardware Abstraction (approved) [qemu; emulation]
SPEC_ARCH_QEMU_BUILD_1: QEMU Component Selection (approved) [qemu; build]
SPEC_ARCH_TASKS_1: FreeRTOS Task Organization (approved) [threading; rtos]
SPEC_ARCH_MEMORY_1: Memory Management Strategy (approved) [memory; performance]
SPEC_ARCH_BUILD_1: ESP-IDF CMake Integration (approved) [build; cmake]
SPEC_ARCH_FLASH_1: Flash Memory Configuration (approved) [flash; memory]
SPEC_ARCH_CODESPACES_1: GitHub Codespaces Integration (approved) [development; devcontainer]
SPEC_ARCH_LOGGING_1: Logging and Diagnostics Strategy (approved) [logging; diagnostics; debugging]
SPEC_ARCH_ERROR_RECOVERY_1: Error Recovery and Reset Strategy (approved) [error-handling; reliability; reset]
SPEC_ARCH_PERF_1: System Performance Requirements (approved) [performance; requirements]
SPEC_DEV_LIMITS_STRUCTURE: Known Limitations File Structure and Process (implemented) [developer; limitations; known-issues]
SPEC_LED_ARCH_1: RMT Peripheral Hardware Abstraction (approved) [led; rmt; hardware]
SPEC_LED_ARCH_2: RAM Buffer Architecture (approved) [led; memory; buffer]
SPEC_LED_API_1: Pixel-Level Control API (approved) [led; api; control]
SPEC_LED_API_2: Batch Operations API (approved) [led; api; batch]
SPEC_LED_API_3: LED State Read API (approved) [led; api; monitoring; thread-safety]
SPEC_LED_TIMING_1: WS2812 Timing Specification (approved) [led; timing; ws2812]
SPEC_LED_DATA_1: Color Representation and Conversion (approved) [led; color; conversion]
SPEC_LED_MEM_1: Dynamic Memory Management (approved) [led; memory; resource]
SPEC_LED_ERR_1: Error Handling and Validation (approved) [led; error-handling; validation]
SPEC_LED_SIM_1: LED Controller Simulator (approved) [led; simulator; qemu]
SPEC_NETIF_UART_ARCH_1: UART Tunnel Component Architecture (implemented) [netif; qemu; uart; architecture]
SPEC_NETIF_UART_PROTO_1: UART Wire Protocol — Length-Prefix Framing (implemented) [netif; qemu; protocol; framing]
SPEC_NETIF_UART_BRIDGE_1: Host-Side Serial-TUN Bridge Script (implemented) [netif; qemu; python; bridge; tooling]
SPEC_NETIF_UART_DHCP_1: IP Configuration and DHCP Client Integration (implemented) [netif; qemu; dhcp; ip]
SPEC_NETIF_UART_COND_1: Conditional Compilation — QEMU-Only Build Guard (implemented) [netif; qemu; build; kconfig]
SPEC_NETIF_UART_PERF_1: Performance Characteristics and Known Limitations (implemented) [netif; qemu; performance; limitations]
SPEC_NETIF_UART_DOC_1: Emulation Setup Documentation (implemented) [netif; qemu; documentation]
SPEC_STARTUP_1: LED Controller Dependency Design (approved) [startup; initialization; dependency]
SPEC_STARTUP_2: Sequential LED Pattern Algorithm (approved) [startup; algorithm; visual]
SPEC_STARTUP_3: Startup Integration and Cleanup (approved) [startup; integration; cleanup]
SPEC_STARTUP_4: Component Architecture (approved) [startup; architecture; component]
SPEC_WEB_ARCH_1: Web Server Architecture (approved) [web; architecture]
SPEC_WEB_STATIC_1: Static File Embedding Strategy (approved) [web; build; embedding]
SPEC_WEB_ROUTES_1: URI Routing Table (approved) [web; routing]
SPEC_WEB_REST_CFG_1: Configuration API Endpoints (approved) [web; api; config; schema]
SPEC_WEB_REST_WIFI_1: WiFi Management REST API Endpoints (approved) [web; api; wifi]
SPEC_WEB_REST_HEALTH_1: System Health API Endpoint (approved) [web; api; diagnostics]
SPEC_WEB_REST_LED_1: LED State API Endpoint (approved) [web; api; led; visualization]
SPEC_WEB_INTEGRATION_CFG_1: Config Manager Integration Pattern (approved) [web; integration; config]
SPEC_WEB_INTEGRATION_WIFI_1: WiFi Manager Integration Pattern (approved) [web; integration; wifi]
SPEC_WEB_CAPTIVE_1: Captive Portal Design (approved) [web; captive-portal; wifi]
SPEC_WEB_CONFIG_1: HTTP Server Configuration (approved) [web; config; performance]
SPEC_WEB_EXTEND_1: Extension Guide for Web Pages (approved) [web; extensibility; guide]
SPEC_WEB_SECURITY_1: CORS Configuration (approved) [web; security; cors]
SPEC_WEB_TEST_1: Web Server Testing Strategy (approved) [web; testing]
SPEC_WEB_NF_1: Mobile-First Responsive Design (approved) [web; ui; mobile; responsive]
API_COMP_CERT_HANDLER: Certificate Handler (implemented)
API_FUNC_CERT_HANDLER_INIT: cert_handler_init (implemented)
API_FUNC_CERT_HANDLER_GET_SERVER_CERT: cert_handler_get_server_cert (implemented)
API_FUNC_CERT_HANDLER_GET_SERVER_KEY: cert_handler_get_server_key (implemented)
API_FUNC_CERT_HANDLER_GET_CA_CERT: cert_handler_get_ca_cert (implemented)
API_FUNC_CERT_HANDLER_GET_INFO: cert_handler_get_info (implemented)
API_COMP_CONFIG_MANAGER: Config Manager (implemented)
API_FUNC_CONFIG_INIT: config_init (implemented)
API_FUNC_CONFIG_FACTORY_RESET: config_factory_reset (implemented)
API_FUNC_CONFIG_COMMIT: config_commit (implemented)
API_FUNC_CONFIG_WRITE_FACTORY_DEFAULTS: config_write_factory_defaults (implemented)
API_FUNC_CONFIG_GET_STRING: config_get_string (implemented)
API_FUNC_CONFIG_SET_STRING: config_set_string (implemented)
API_FUNC_CONFIG_SET_STRING_NO_COMMIT: config_set_string_no_commit (implemented)
API_FUNC_CONFIG_GET_INT32: config_get_int32 (implemented)
API_FUNC_CONFIG_SET_INT32: config_set_int32 (implemented)
API_FUNC_CONFIG_GET_INT16: config_get_int16 (implemented)
API_FUNC_CONFIG_SET_INT16: config_set_int16 (implemented)
API_FUNC_CONFIG_SET_INT16_NO_COMMIT: config_set_int16_no_commit (implemented)
API_FUNC_CONFIG_GET_BOOL: config_get_bool (implemented)
API_FUNC_CONFIG_SET_BOOL_NO_COMMIT: config_set_bool_no_commit (implemented)
API_FUNC_CONFIG_SET_BOOL: config_set_bool (implemented)
API_FUNC_CONFIG_GET_SCHEMA_JSON: config_get_schema_json (implemented)
API_FUNC_CONFIG_GET_ALL_AS_JSON: config_get_all_as_json (implemented)
API_FUNC_CONFIG_SET_ALL_FROM_JSON: config_set_all_from_json (implemented)
API_COMP_DISPLAY_LOGIC: Display Logic (implemented)
API_FUNC_DISPLAY_LOGIC_START: display_logic_start (implemented)
API_COMP_DISTANCE_SENSOR: Distance Sensor (implemented)
API_FUNC_DISTANCE_SENSOR_INIT: distance_sensor_init (implemented)
API_FUNC_DISTANCE_SENSOR_START: distance_sensor_start (implemented)
API_FUNC_DISTANCE_SENSOR_STOP: distance_sensor_stop (implemented)
API_FUNC_DISTANCE_SENSOR_GET_LATEST: distance_sensor_get_latest (implemented)
API_FUNC_DISTANCE_SENSOR_HAS_NEW_MEASUREMENT: distance_sensor_has_new_measurement (implemented)
API_FUNC_DISTANCE_SENSOR_GET_QUEUE_OVERFLOWS: distance_sensor_get_queue_overflows (implemented)
API_FUNC_DISTANCE_SENSOR_MONITOR: distance_sensor_monitor (implemented)
API_FUNC_DISTANCE_SENSOR_IS_RUNNING: distance_sensor_is_running (implemented)
API_STRUCT_DISTANCE_SENSOR_ERROR: distance_sensor_error_t (implemented)
API_STRUCT_DISTANCE_SENSOR_RAW_MEASUREMENT: distance_raw_measurement_t (implemented)
API_STRUCT_DISTANCE_SENSOR_MEASUREMENT: distance_measurement_t (implemented)
API_COMP_LED_CONTROLLER: LED Controller (implemented)
API_STRUCT_LED_COLOR: led_color_t (implemented)
API_FUNC_LED_CONTROLLER_INIT: led_controller_init (implemented)
API_FUNC_LED_CONTROLLER_DEINIT: led_controller_deinit (implemented)
API_FUNC_LED_SET_PIXEL: led_set_pixel (implemented)
API_FUNC_LED_CLEAR_PIXEL: led_clear_pixel (implemented)
API_FUNC_LED_GET_PIXEL: led_get_pixel (implemented)
API_FUNC_LED_CLEAR_ALL: led_clear_all (implemented)
API_FUNC_LED_SHOW: led_show (implemented)
API_FUNC_LED_COLOR_RGB: led_color_rgb (implemented)
API_FUNC_LED_COLOR_BRIGHTNESS: led_color_brightness (implemented)
API_FUNC_LED_GET_COUNT: led_get_count (implemented)
API_FUNC_LED_IS_INITIALIZED: led_is_initialized (implemented)
API_FUNC_LED_GET_ALL_COLORS: led_get_all_colors (implemented)
API_COMP_NETIF_TUNNEL: Network Tunnel (implemented)
API_STRUCT_NETIF_TUNNEL_CONFIG: netif_uart_tunnel_config_t (implemented)
API_FUNC_NETIF_TUNNEL_INIT: netif_uart_tunnel_init (implemented)
API_FUNC_NETIF_TUNNEL_DEINIT: netif_uart_tunnel_deinit (implemented)
API_FUNC_NETIF_TUNNEL_GET_HANDLE: netif_uart_tunnel_get_handle (implemented)
API_COMP_STARTUP_TESTS: Startup Tests (implemented)
API_FUNC_STARTUP_TESTS_SINGLE_CYCLE: led_running_test_single_cycle (implemented)
API_FUNC_STARTUP_TESTS_MULTIPLE_CYCLES: led_running_test_multiple_cycles (implemented)
API_FUNC_STARTUP_TESTS_RAINBOW: led_running_test_rainbow (implemented)
API_COMP_WEB_SERVER: Web Server (implemented)
API_FUNC_WEB_INIT: web_server_init (implemented)
API_FUNC_WEB_START: web_server_start (implemented)
API_FUNC_WEB_STOP: web_server_stop (implemented)
API_FUNC_WEB_IS_RUNNING: web_server_is_running (implemented)
API_FUNC_WEB_GET_PORT: web_server_get_port (implemented)
API_FUNC_WEB_STATIC_FILE: static_file_handler (implemented)
API_STRUCT_WEB_CONFIG: web_server_config_t (implemented)
API_COMP_WIFI_MGR: WiFi Manager (implemented)
API_FUNC_WIFI_INIT: wifi_manager_init (implemented)
API_FUNC_WIFI_START: wifi_manager_start (implemented)
API_FUNC_WIFI_STOP: wifi_manager_stop (implemented)
API_FUNC_WIFI_GET_STATUS: wifi_manager_get_status (implemented)
API_FUNC_WIFI_SET_CRED: wifi_manager_set_credentials (implemented)
API_FUNC_WIFI_CLEAR_CRED: wifi_manager_clear_credentials (implemented)
API_FUNC_WIFI_GET_IP: wifi_manager_get_ip_address (implemented)
API_FUNC_WIFI_SWITCH_AP: wifi_manager_switch_to_ap (implemented)
API_FUNC_WIFI_MONITOR: wifi_manager_monitor (implemented)
API_STRUCT_WIFI_MODE: wifi_manager_mode_t (implemented)
API_STRUCT_WIFI_CRED: wifi_credentials_t (implemented)
API_STRUCT_WIFI_STATUS: wifi_status_t (implemented)
