JSON-Based Configuration Manager Requirements

This document specifies component-level requirements for the JSON-Schema-Driven Configuration Management System. These requirements refine the high-level system requirement Non-volatile Configuration ... (REQ_SYS_CFG_1) (Non-volatile Configuration Storage).

Component Overview

The JSON-based configuration manager component provides centralized configuration management through a single JSON schema source of truth. Configuration is stored persistently in NVS and accessed via type-safe C API. The web interface generates forms dynamically from the schema.

Configuration Schema Definition

Requirement: JSON Schema as Configuration Source of Truth REQ_CFG_JSON_1

status: draft tags: config, schema, architecture priority: mandatory links outgoing: REQ_SYS_CFG_1 links incoming: REQ_CFG_JSON_2, REQ_CFG_JSON_3, REQ_CFG_JSON_4, REQ_CFG_JSON_6, REQ_CFG_JSON_10, REQ_CFG_JSON_13, REQ_CFG_JSON_15, SPEC_CFG_JSON_ARCH_1, SPEC_CFG_JSON_SOURCE_1, SPEC_CFG_JSON_SCHEMA_1, SPEC_CFG_JSON_CODEGEN_1, SPEC_CFG_JSON_EXTEND_1, API_COMP_CONFIG_MANAGER

Description: The configuration manager SHALL define all configuration parameters in a single JSON schema file (config_schema.json) that serves as the authoritative source of truth for parameter definitions, default values, and UI metadata. Rationale: Single source of truth prevents duplication across C code, web forms, and documentation. Schema-driven approach enables code generation for factory defaults and dynamic UI generation. Acceptance Criteria: AC-1: JSON schema file SHALL define all user-configurable parameters AC-2: Schema SHALL include parameter type, label, default value, and validation constraints AC-3: Parameters organized in groups for UI section structure AC-4: Schema SHALL be embeddable in flash for browser access AC-5: Schema format SHALL be human-readable and maintainable

Requirement: Parameter Grouping for UI Organization REQ_CFG_JSON_2

status: draft tags: config, ui, schema priority: optional links outgoing: REQ_CFG_JSON_1 links incoming: SPEC_CFG_JSON_SCHEMA_1

Description: The configuration schema SHALL support logical grouping of parameters into sections for organization in the web interface. Rationale: Logical organization improves usability for configuration with many parameters. Acceptance Criteria: AC-1: Each group SHALL have id, label, and description AC-2: Fields SHALL reference group by id AC-3: UI SHALL display fields grouped and ordered as specified in schema AC-4: Each group SHALL be collapsible/expandable (optional UI feature)

Requirement: Parameter Type System REQ_CFG_JSON_3

status: draft tags: config, types priority: mandatory links outgoing: REQ_CFG_JSON_1 links incoming: SPEC_CFG_JSON_SCHEMA_1

Description: The configuration system SHALL support basic parameter types: string, password, integer, boolean, and hidden. Rationale: Covers typical IoT configuration needs while remaining simple. Separate types enable appropriate UI widgets and validation. Acceptance Criteria: AC-1: String type SHALL support min/max length and regex pattern validation AC-2: Password type SHALL be string type with hidden display in UI AC-3: Integer type SHALL support min/max range and step constraints AC-4: Boolean type SHALL map to checkbox in UI AC-5: Hidden type SHALL not appear in web form (internal config)

Configuration Generation and Defaults

Requirement: Build-Time Factory Defaults Generation REQ_CFG_JSON_4

status: draft tags: config, build, code-generation priority: mandatory links outgoing: REQ_CFG_JSON_1, REQ_SYS_CFG_1 links incoming: REQ_CFG_JSON_5, REQ_CFG_JSON_9, SPEC_CFG_JSON_CODEGEN_1, API_COMP_CONFIG_MANAGER, API_FUNC_CONFIG_WRITE_FACTORY_DEFAULTS

Description: The build system SHALL automatically generate C code to initialize factory default configuration from the JSON schema during build time. Rationale: Eliminates manual default value maintenance in C code. Generated code is compiled into firmware, ensuring defaults match schema without runtime JSON parsing. Acceptance Criteria: AC-1: Python script SHALL parse config_schema.json during build AC-2: Script SHALL generate config_factory_generated.c with config_write_factory_defaults() function AC-3: Generated function SHALL call config_set_xxx() for each schema field with default value AC-4: Build SHALL fail if schema is invalid JSON AC-5: Generated code SHALL be included in firmware compilation

Requirement: No Runtime JSON Parsing in C Code REQ_CFG_JSON_5

status: draft tags: config, performance, memory priority: mandatory links outgoing: REQ_CFG_JSON_4 links incoming: SPEC_CFG_JSON_CODEGEN_1

Description: The ESP32 application code SHALL NOT parse JSON at runtime. JSON parsing SHALL occur only at build time (code generation) or in browser (UI). Rationale: Eliminates runtime overhead and memory overhead of JSON parser on resource-constrained ESP32. Simplifies C code and improves performance. Acceptance Criteria: AC-1: C code SHALL NOT include JSON parser library AC-2: NVS access SHALL use direct key-value API (no JSON deserialization) AC-3: Factory reset SHALL call pre-generated config_write_factory_defaults() function AC-4: Runtime memory usage SHALL not include JSON parser structures

NVS Storage and Access

Requirement: Key-Based NVS Storage REQ_CFG_JSON_6

status: draft tags: config, storage, nvs priority: mandatory links outgoing: REQ_CFG_JSON_1, REQ_SYS_CFG_1 links incoming: REQ_CFG_JSON_7, REQ_CFG_JSON_8, REQ_CFG_JSON_11, REQ_CFG_JSON_12, SPEC_CFG_JSON_ARCH_1, SPEC_CFG_JSON_STORAGE_1, SPEC_CFG_JSON_API_1, API_COMP_CONFIG_MANAGER

Description: Configuration parameters SHALL be stored in NVS using the schema “key” field directly as the NVS key. Rationale: Direct key usage simplifies storage format and eliminates need for separate UUID system. Keys are human-readable for debugging. Acceptance Criteria: AC-1: Each schema field key SHALL be valid NVS key (≤15 characters) AC-2: NVS storage SHALL use “config” namespace for isolation AC-3: Parameter values SHALL be stored individually (not as single blob) AC-4: NVS key SHALL directly match schema field key

Requirement: Type-Safe Configuration API REQ_CFG_JSON_7

status: draft tags: config, api, type-safety priority: mandatory links outgoing: REQ_CFG_JSON_6 links incoming: REQ_CFG_JSON_10, REQ_CFG_JSON_14, REQ_WEB_2, SPEC_CFG_JSON_API_1, SPEC_CFG_JSON_TYPESAFETY_1, API_COMP_CONFIG_MANAGER, API_FUNC_CONFIG_GET_STRING, API_FUNC_CONFIG_SET_STRING, API_FUNC_CONFIG_GET_INT32, API_FUNC_CONFIG_SET_INT32, API_FUNC_CONFIG_GET_INT16, API_FUNC_CONFIG_SET_INT16, API_FUNC_CONFIG_GET_BOOL, API_FUNC_CONFIG_SET_BOOL

Description: The configuration manager SHALL provide type-specific getter and setter functions for configuration access. Rationale: Type-specific functions enforce compile-time type checking via function signature. Different functions for different types prevent accidental type mismatches at call site. Acceptance Criteria: AC-1: Getters SHALL be: config_get_string(), config_get_int32(), config_get_int16(), config_get_bool() AC-2: Setters SHALL be: config_set_string(), config_set_int32(), config_set_int16(), config_set_bool() AC-3: All functions SHALL take key as string parameter (matches schema key) AC-4: Functions SHALL return ESP_OK or error code (ESP_ERR_INVALID_ARG, ESP_ERR_NVS_*) AC-5: Caller SHALL use matching function for parameter type in schema

Requirement: Persistent Configuration Storage REQ_CFG_JSON_8

status: draft tags: config, storage, nvs priority: mandatory links outgoing: REQ_CFG_JSON_6 links incoming: SPEC_CFG_JSON_STORAGE_1, API_COMP_CONFIG_MANAGER

Description: Configuration changes SHALL be immediately persisted to NVS on each config_set_xxx() call. Rationale: Ensures configuration survives power loss and system resets. Acceptance Criteria: AC-1: config_set_xxx() SHALL write to NVS before returning AC-2: Write failures SHALL be logged but not crash system AC-3: Configuration SHALL be reloaded from NVS on next system boot AC-4: NVS corruption SHALL be handled gracefully with defaults

Requirement: Factory Reset Capability REQ_CFG_JSON_9

status: draft tags: config, reset priority: mandatory links outgoing: REQ_CFG_JSON_4, REQ_SYS_CFG_1 links incoming: SPEC_CFG_JSON_CODEGEN_1, API_COMP_CONFIG_MANAGER, API_FUNC_CONFIG_FACTORY_RESET

Description: The system SHALL provide config_factory_reset() function to reset all configuration to schema-defined defaults. Rationale: Users need ability to recover from misconfiguration without firmware rebuild. Acceptance Criteria: AC-1: Factory reset SHALL erase all values in “config” NVS namespace AC-2: Factory reset SHALL call config_write_factory_defaults() to restore defaults AC-3: Factory reset SHALL return success/error status AC-4: Factory reset errors SHALL be logged

Web Interface Integration

Requirement: Web Interface Integration Support REQ_CFG_JSON_10

status: approved tags: config, integration priority: optional links outgoing: REQ_SYS_WEB_1, REQ_CFG_JSON_1, REQ_CFG_JSON_7 links incoming: SPEC_CFG_JSON_UI_1, SPEC_WEB_INTEGRATION_CFG_1

Description: The configuration system SHOULD provide integration points for web-based configuration interfaces. Rationale: Web servers need access to configuration schema and runtime values to provide user interfaces. Config Manager provides the data layer; Web Server provides the HTTP/UI layer. Acceptance Criteria: AC-1: Configuration schema file (config_schema.json) SHALL be embeddable in web server AC-2: C API functions (config_get_*, config_set_*) SHALL be callable from web request handlers AC-3: Schema format SHALL support web form generation use cases AC-4: API SHALL return error codes suitable for HTTP status mapping Note: Detailed web interface requirements (HTML forms, REST API endpoints, validation) are specified in Web Server Requirements (Configuration REST API (REQ_WEB_CONF_1)). This requirement ensures Config Manager provides necessary integration points without knowing HTTP details.

Error Handling

Requirement: NVS Error Graceful Handling REQ_CFG_JSON_11

status: draft tags: config, error-handling, reliability priority: mandatory links outgoing: REQ_CFG_JSON_6, REQ_SYS_REL_1 links incoming: REQ_CFG_JSON_12, SPEC_CFG_JSON_UI_1, API_COMP_CONFIG_MANAGER

Description: The configuration system SHALL gracefully handle NVS errors and continue operating with default values. Rationale: NVS corruption or wear should not prevent system operation. Acceptance Criteria: AC-1: NVS read failures SHALL log error and use schema default value AC-2: NVS write failures SHALL log error but not crash application AC-3: System SHALL boot successfully even if NVS namespace is corrupted AC-4: Web interface SHALL indicate NVS error status to user

Requirement: Configuration Initialization on Boot REQ_CFG_JSON_12

status: draft tags: config, boot priority: mandatory links outgoing: REQ_CFG_JSON_6, REQ_CFG_JSON_11 links incoming: SPEC_CFG_JSON_BULK_1, SPEC_CFG_WEB_ARCH_1, API_COMP_CONFIG_MANAGER, API_FUNC_CONFIG_INIT, API_FUNC_CONFIG_GET_SCHEMA_JSON, API_FUNC_CONFIG_GET_ALL_AS_JSON

Description: On first boot, config_init() SHALL initialize NVS with factory defaults from schema if NVS “config” namespace is empty or uninitialized. Rationale: New devices need sensible defaults on first boot. Acceptance Criteria: AC-1: config_init() SHALL check if NVS “config” namespace exists AC-2: If empty, config_init() SHALL call config_factory_reset() to write defaults AC-3: On subsequent boots, config_init() SHALL load values from NVS AC-4: Process SHALL be atomic (no partial updates)

Development Guide

Requirement: Simple Process to Add Configuration Fields REQ_CFG_JSON_13

status: draft tags: config, extensibility, developer-experience priority: optional links outgoing: REQ_CFG_JSON_1 links incoming: SPEC_CFG_JSON_BULK_1, SPEC_CFG_JSON_EXTEND_1, SPEC_CFG_WEB_ARCH_1, API_COMP_CONFIG_MANAGER, API_FUNC_CONFIG_SET_ALL_FROM_JSON

Description: Adding new configuration parameters SHALL require modification of only config_schema.json, with C code and web UI auto-updating. Rationale: Low friction for extending configuration reduces development time. Acceptance Criteria: AC-1: New field added to config_schema.json SHALL appear in web form on next page reload AC-2: Developer SHALL call config_get_xxx(“key”) in C code matching schema key AC-3: Factory defaults auto-generated from schema (no manual C code needed) AC-4: Documentation SHALL provide step-by-step guide for adding fields

Requirement: Type Safety via Optional Static Validation REQ_CFG_JSON_14

status: draft tags: config, validation, developer-experience priority: optional links outgoing: REQ_CFG_JSON_7 links incoming: SPEC_CFG_JSON_TYPESAFETY_1

Description: The build system SHOULD provide optional pre-build validation script that detects type mismatches between schema and C code. Rationale: Catches developer errors early without requiring code generation. Optional to keep build simple. Acceptance Criteria: AC-1: Validator script SHALL parse config_schema.json AC-2: Script SHALL search C source files for config_get_xxx(“key”) calls AC-3: Script SHALL verify function type matches schema type AC-4: Script SHALL output errors for mismatches AC-5: Integration into build pipeline SHALL be optional (can be skipped)

Future Enhancements

Requirement: Configuration Schema Versioning and Migration REQ_CFG_JSON_15

status: open tags: config, versioning, migration, future priority: optional links outgoing: REQ_CFG_JSON_1

Description: The configuration system MAY support schema versioning and automatic migration of configuration data across firmware updates. Rationale: As firmware evolves, configuration structure may change (new fields, renamed keys, changed types). Schema versioning enables detection and migration of old configurations. However, embedded devices are typically “programmed out” thoroughly before production deployment, minimizing schema changes after deployment. Acceptance Criteria (if implemented): AC-1: config_schema.json includes “schema_version” field AC-2: config_init() detects NVS schema version mismatch AC-3: Migration functions upgrade old config to new schema AC-4: Migration preserves user settings where possible AC-5: Failed migration triggers factory reset with user warning Note: This requirement is marked “open” as schema changes are rare in production embedded systems. Hardware constraints typically stabilize configuration structure early in development. For most deployments, factory reset on major firmware updates is acceptable alternative to complex migration logic.

Traceability

All traceability is automatically generated by Sphinx-Needs based on the :links: attributes in each requirement.

ID	Title	Status	Tags
API_COMP_CERT_HANDLER	Certificate Handler	implemented
API_COMP_CONFIG_MANAGER	Config Manager	implemented
API_COMP_NETIF_TUNNEL	Network Tunnel	implemented
API_FUNC_CERT_HANDLER_GET_CA_CERT	cert_handler_get_ca_cert	implemented
API_FUNC_CERT_HANDLER_GET_INFO	cert_handler_get_info	implemented
API_FUNC_CERT_HANDLER_GET_SERVER_CERT	cert_handler_get_server_cert	implemented
API_FUNC_CERT_HANDLER_GET_SERVER_KEY	cert_handler_get_server_key	implemented
API_FUNC_CERT_HANDLER_INIT	cert_handler_init	implemented
API_FUNC_CONFIG_COMMIT	config_commit	implemented
API_FUNC_CONFIG_FACTORY_RESET	config_factory_reset	implemented
API_FUNC_CONFIG_GET_ALL_AS_JSON	config_get_all_as_json	implemented
API_FUNC_CONFIG_GET_BOOL	config_get_bool	implemented
API_FUNC_CONFIG_GET_INT16	config_get_int16	implemented
API_FUNC_CONFIG_GET_INT32	config_get_int32	implemented
API_FUNC_CONFIG_GET_SCHEMA_JSON	config_get_schema_json	implemented
API_FUNC_CONFIG_GET_STRING	config_get_string	implemented
API_FUNC_CONFIG_INIT	config_init	implemented
API_FUNC_CONFIG_SET_ALL_FROM_JSON	config_set_all_from_json	implemented
API_FUNC_CONFIG_SET_BOOL	config_set_bool	implemented
API_FUNC_CONFIG_SET_BOOL_NO_COMMIT	config_set_bool_no_commit	implemented
API_FUNC_CONFIG_SET_INT16	config_set_int16	implemented
API_FUNC_CONFIG_SET_INT16_NO_COMMIT	config_set_int16_no_commit	implemented
API_FUNC_CONFIG_SET_INT32	config_set_int32	implemented
API_FUNC_CONFIG_SET_STRING	config_set_string	implemented
API_FUNC_CONFIG_SET_STRING_NO_COMMIT	config_set_string_no_commit	implemented
API_FUNC_CONFIG_WRITE_FACTORY_DEFAULTS	config_write_factory_defaults	implemented
API_FUNC_NETIF_TUNNEL_DEINIT	netif_uart_tunnel_deinit	implemented
API_FUNC_NETIF_TUNNEL_GET_HANDLE	netif_uart_tunnel_get_handle	implemented
API_FUNC_NETIF_TUNNEL_INIT	netif_uart_tunnel_init	implemented
API_STRUCT_NETIF_TUNNEL_CONFIG	netif_uart_tunnel_config_t	implemented
REQ_CFG_JSON_1	JSON Schema as Configuration Source of Truth	draft	config; schema; architecture
REQ_CFG_JSON_10	Web Interface Integration Support	approved	config; integration
REQ_CFG_JSON_11	NVS Error Graceful Handling	draft	config; error-handling; reliability
REQ_CFG_JSON_12	Configuration Initialization on Boot	draft	config; boot
REQ_CFG_JSON_13	Simple Process to Add Configuration Fields	draft	config; extensibility; developer-experience
REQ_CFG_JSON_14	Type Safety via Optional Static Validation	draft	config; validation; developer-experience
REQ_CFG_JSON_15	Configuration Schema Versioning and Migration	open	config; versioning; migration; future
REQ_CFG_JSON_2	Parameter Grouping for UI Organization	draft	config; ui; schema
REQ_CFG_JSON_3	Parameter Type System	draft	config; types
REQ_CFG_JSON_4	Build-Time Factory Defaults Generation	draft	config; build; code-generation
REQ_CFG_JSON_5	No Runtime JSON Parsing in C Code	draft	config; performance; memory
REQ_CFG_JSON_6	Key-Based NVS Storage	draft	config; storage; nvs
REQ_CFG_JSON_7	Type-Safe Configuration API	draft	config; api; type-safety
REQ_CFG_JSON_8	Persistent Configuration Storage	draft	config; storage; nvs
REQ_CFG_JSON_9	Factory Reset Capability	draft	config; reset
REQ_NETIF_TUNNEL_1	QEMU UART Network Bridge	approved	emulation; network; qemu; uart
REQ_NETIF_TUNNEL_2	Packet Encapsulation	approved	emulation; protocol
REQ_NETIF_TUNNEL_3	Host-Side Bridge Script	approved	emulation; tooling; host
REQ_NETIF_TUNNEL_4	DHCP Client Support	approved	emulation; network; dhcp
REQ_NETIF_TUNNEL_5	Conditional Compilation	approved	emulation; build
REQ_NETIF_TUNNEL_DOC_1	Emulation Setup Documentation	approved	emulation; documentation
REQ_NETIF_TUNNEL_NF_1	Tunnel Throughput	approved	emulation; performance
REQ_NETIF_TUNNEL_NF_2	Packet Loss Handling	approved	emulation; reliability
REQ_SYS_ARCH_1	Component-based Architecture	approved	architecture; modularity
REQ_SYS_CFG_1	Non-volatile Configuration Storage	approved	storage; nvs; configuration
REQ_SYS_HW_1	ESP32 Hardware Platform	approved	hardware; platform
REQ_SYS_NET_1	WiFi Connectivity	approved	network; wifi
REQ_SYS_PERF_1	Memory Management	approved	performance; memory
REQ_SYS_REL_1	Error Handling and Recovery	approved	reliability; error-handling
REQ_SYS_SEC_1	HTTPS Support	open	security; https; future
REQ_SYS_SIM_1	Emulator Support	approved	emulator; qemu; testing
REQ_SYS_SIM_2	Emulator Network Connectivity	approved	emulator; qemu; network; development
REQ_SYS_TIME_1	System Time and NTP Support	open	time; ntp; future
REQ_SYS_WEB_1	Web-based Configuration	approved	web; configuration
REQ_WEB_1	Real-time Status Display	approved	web; ui; monitoring
REQ_WEB_2	Configuration Interface	approved	web; ui; configuration
REQ_WEB_3	WiFi Setup Interface	approved	web; wifi; network
REQ_WEB_4	Web Interface Navigation	approved	web; ui; navigation
REQ_WEB_5	HTTP Server Concurrency	approved	web; performance
REQ_WEB_CONF_1	Configuration REST API	approved	web; api; config
REQ_WEB_NF_1	Web UI Responsiveness	approved	web; performance; ux
REQ_WEB_NF_2	Mobile-First Design	approved	web; ui; mobile
REQ_WEB_SCHEMA_1	Schema-Driven Configuration Form	approved	web; ui; config
SPEC_ARCH_BUILD_1	ESP-IDF CMake Integration	approved	build; cmake
SPEC_ARCH_CERT_1	Certificate Handler Component Design	draft	component; security
SPEC_ARCH_CODESPACES_1	GitHub Codespaces Integration	approved	development; devcontainer
SPEC_ARCH_COMM_1	Component Communication Pattern	approved	dataflow; communication
SPEC_ARCH_CONFIG_1	Configuration Manager Component Design	approved	component; config
SPEC_ARCH_CONFIG_FLOW_1	Configuration Data Flow	approved	dataflow; config
SPEC_ARCH_ERROR_RECOVERY_1	Error Recovery and Reset Strategy	approved	error-handling; reliability; reset
SPEC_ARCH_FLASH_1	Flash Memory Configuration	approved	flash; memory
SPEC_ARCH_HTTP_1	HTTP Server Architecture Details	approved	network; http; web
SPEC_ARCH_LAYERS_1	ESP32 Template Layered Architecture	approved	architecture; layering
SPEC_ARCH_LOGGING_1	Logging and Diagnostics Strategy	approved	logging; diagnostics; debugging
SPEC_ARCH_MEMORY_1	Memory Management Strategy	approved	memory; performance
SPEC_ARCH_NETIF_1	Network Tunnel Component Design	approved	component; qemu; network
SPEC_ARCH_PERF_1	System Performance Requirements	approved	performance; requirements
SPEC_ARCH_QEMU_1	QEMU Hardware Abstraction	approved	qemu; emulation
SPEC_ARCH_QEMU_BUILD_1	QEMU Component Selection	approved	qemu; build
SPEC_ARCH_TASKS_1	FreeRTOS Task Organization	approved	threading; rtos
SPEC_ARCH_WEB_1	Web Server Component Design	approved	component; web; network
SPEC_ARCH_WIFI_1	WiFi Manager Design Details	approved	network; wifi
SPEC_CFG_JSON_API_1	Type-Safe Configuration API	approved	api; interface; c-api
SPEC_CFG_JSON_ARCH_1	JSON Schema-Driven Architecture	draft	architecture; config; json-schema
SPEC_CFG_JSON_BULK_1	Bulk JSON Configuration API	approved	api; json; bulk-operations
SPEC_CFG_JSON_CODEGEN_1	Factory Reset via Bulk JSON Update	approved	build-process; code-generation; factory-reset
SPEC_CFG_JSON_EXTEND_1	Adding New Configuration Fields	approved	development; guide; extensibility
SPEC_CFG_JSON_SCHEMA_1	Configuration Schema Structure	approved	data-structure; schema
SPEC_CFG_JSON_SOURCE_1	JSON Schema as Single Source of Truth	approved	architecture; schema; design-pattern
SPEC_CFG_JSON_STORAGE_1	NVS Storage Format	approved	storage; nvs
SPEC_CFG_JSON_TYPESAFETY_1	Type Safety Without Code Generation	approved	type-safety; best-practices
SPEC_CFG_JSON_UI_1	JSON Schema for UI Generation	approved	web; ui; javascript
SPEC_CFG_WEB_ARCH_1	Configuration Webpage Architecture	open	frontend; javascript; ui
SPEC_CFG_WEB_COUNTDOWN_1	Device Reset Countdown Interface	open	ui; countdown; reset
SPEC_CFG_WEB_ERROR_1	Error Handling and User Feedback	open	error-handling; feedback
SPEC_CFG_WEB_FLOW_1	Configuration Data Flow	open	data-flow; json; api
SPEC_CFG_WEB_FORM_1	Dynamic Form Generation from Schema	open	form-generation; schema; javascript
SPEC_CFG_WEB_INIT_1	Complete Page Initialization Flow	open	initialization; lifecycle
SPEC_CFG_WEB_MAPPING_1	JSON Array to Form Field Mapping	open	data-mapping; json; form
SPEC_CFG_WEB_STATE_1	UI State Management	open	ui-state; javascript
SPEC_WEB_ARCH_1	Web Server Architecture	approved	web; architecture
SPEC_WEB_CAPTIVE_1	Captive Portal Design	approved	web; captive-portal; wifi
SPEC_WEB_CONFIG_1	HTTP Server Configuration	approved	web; config; performance
SPEC_WEB_EXTEND_1	Extension Guide for Web Pages	approved	web; extensibility; guide
SPEC_WEB_INTEGRATION_CFG_1	Config Manager Integration Pattern	approved	web; integration; config
SPEC_WEB_INTEGRATION_WIFI_1	WiFi Manager Integration Pattern	approved	web; integration; wifi
SPEC_WEB_REST_CFG_1	Configuration API Endpoints	approved	web; api; config; schema
SPEC_WEB_REST_HEALTH_1	System Health API Endpoint	approved	web; api; diagnostics
SPEC_WEB_REST_WIFI_1	WiFi Management REST API Endpoints	approved	web; api; wifi
SPEC_WEB_ROUTES_1	URI Routing Table	approved	web; routing
SPEC_WEB_SECURITY_1	CORS Configuration	approved	web; security; cors
SPEC_WEB_STATIC_1	Static File Embedding Strategy	approved	web; build; embedding
SPEC_WEB_TEST_1	Web Server Testing Strategy	approved	web; testing

REQ_CFG_JSON_1
