Network Interface Tunnel Requirements¶
This document specifies component-level requirements for the UART-based network tunnel driver, enabling QEMU emulation with external network connectivity.
Component Overview¶
The network interface tunnel component provides a bridge between QEMU’s simulated UART and the host’s network stack, enabling network-dependent features to be tested in emulation. These requirements refine the high-level system requirement Emulator Support (REQ_SYS_SIM_1).
Functional Requirements¶
Description: The system SHALL provide a custom network interface driver that bridges ESP32’s UART to the host network stack when running in QEMU emulation. Rationale: QEMU does not natively support ESP32 WiFi emulation. A UART tunnel enables network connectivity for testing web server and WiFi-dependent features. Acceptance Criteria:
|
Description: The tunnel driver SHALL encapsulate Ethernet frames for transmission over UART with appropriate framing and error detection. Rationale: UART is a byte-stream transport; Ethernet frame boundaries must be preserved. Acceptance Criteria:
|
Description: The project SHALL provide a Python script that bridges QEMU’s UART to the host’s TAP network interface. Rationale: QEMU UART output must be forwarded to host network stack for external connectivity. Acceptance Criteria:
|
Description: The tunnel network interface SHALL support DHCP client operation to obtain IP address from host network. Rationale: Automatic IP configuration simplifies emulation setup and mirrors real WiFi behavior. Acceptance Criteria:
|
Description: The tunnel driver SHALL be conditionally compiled only when building for QEMU target, with zero overhead on real hardware builds. Rationale: Real hardware uses WiFi driver; tunnel driver is emulation-specific. Acceptance Criteria:
|
Performance Requirements¶
Description: The UART tunnel SHOULD support sufficient throughput for web interface testing (minimum 100 KB/s). Rationale: Web page loads and AJAX updates require reasonable bandwidth. Acceptance Criteria:
|
Description: The tunnel driver SHOULD handle UART packet loss gracefully without crashing. Rationale: QEMU’s UART emulation may occasionally drop bytes under high load. Acceptance Criteria:
|
Documentation Requirements¶
Description: The project SHALL provide clear documentation for setting up and using QEMU emulation with network tunnel. Rationale: Developers need step-by-step instructions to use emulation features. Acceptance Criteria:
|
Traceability¶
All traceability is automatically generated by Sphinx-Needs based on the :links: attributes in each requirement.
