Configuration Webpage Design Specification¶
This document specifies the design of the browser-based configuration interface that provides schema-driven dynamic form generation, bulk configuration management, and factory reset capabilities.
Architecture Overview¶
Overview: The configuration webpage is a single-page JavaScript application that dynamically generates configuration forms from JSON schema and manages all configuration operations through RESTful bulk APIs. Architecture Layers:
Component Dependencies:
|
Data Flow Architecture¶
Page Load Sequence: 1. Browser loads settings.html
↓
2. JavaScript fetches schema: GET /api/config/schema
↓
3. Parse schema → Generate form HTML dynamically
↓
4. Fetch current config: GET /api/config
↓
5. Parse [{key, type, value}, ...] → Update form fields
↓
6. Enable user interaction (Save, Restore, Factory Reset)
Save Configuration Flow: 1. User clicks "Save" button
↓
2. JavaScript collects form values
↓
3. Build structured JSON array:
[
{key: "wifi_ssid", type: "string", value: "MyNetwork"},
{key: "led_count", type: "integer", value: 50},
...
]
↓
4. POST /api/config with JSON body
↓
5. Server responds: 200 OK or error
↓
6. Show success message + reset countdown modal
↓
7. Auto-reload page after countdown (device reboots)
Restore Configuration Flow: 1. User clicks "Restore" button
↓
2. Fetch current config: GET /api/config
↓
3. Parse structured JSON array
↓
4. Update all form fields with current values
↓
5. Show success message
Factory Reset Flow: 1. User clicks "Factory Reset" button
↓
2. Show confirmation dialog: "This will reset all settings!"
↓
3. User confirms
↓
4. POST /api/config/reset
↓
5. Server responds: 200 OK (device will reboot)
↓
6. Show countdown modal: "Device resetting in 5...4...3...2...1"
↓
7. Auto-redirect to WiFi setup page (device rebooted to defaults)
|
Schema-Driven Form Generation¶
Description: JavaScript code that dynamically creates HTML form elements based on JSON schema field definitions. Schema Field Processing: // Input: JSON schema from GET /api/config/schema
const schema = {
"fields": [
{
"key": "wifi_ssid",
"type": "string",
"label": "WiFi SSID",
"description": "Network name to connect",
"default": "",
"validation": {
"required": true,
"maxLength": 32
}
},
{
"key": "led_count",
"type": "integer",
"label": "LED Count",
"description": "Number of LEDs in strip",
"default": 50,
"validation": {
"min": 1,
"max": 300
}
}
]
};
// Process each field to generate form HTML
function generateForm(schema) {
const formContainer = document.getElementById('config-form');
schema.fields.forEach(field => {
const formGroup = createFormGroup(field);
formContainer.appendChild(formGroup);
});
}
Form Element Generation Logic: function createFormGroup(field) {
const group = document.createElement('div');
group.className = 'form-group';
// Create label
const label = document.createElement('label');
label.textContent = field.label;
label.htmlFor = field.key;
// Create input based on type
let input;
switch(field.type) {
case 'string':
input = document.createElement('input');
input.type = field.key.includes('pass') ? 'password' : 'text';
if (field.validation?.maxLength) {
input.maxLength = field.validation.maxLength;
}
if (field.validation?.pattern) {
input.pattern = field.validation.pattern;
}
break;
case 'integer':
input = document.createElement('input');
input.type = 'number';
if (field.validation?.min !== undefined) {
input.min = field.validation.min;
}
if (field.validation?.max !== undefined) {
input.max = field.validation.max;
}
break;
case 'boolean':
input = document.createElement('input');
input.type = 'checkbox';
break;
}
input.id = field.key;
input.name = field.key;
input.required = field.validation?.required || false;
// Create description
const description = document.createElement('small');
description.className = 'form-text';
description.textContent = field.description;
group.appendChild(label);
group.appendChild(input);
group.appendChild(description);
return group;
}
Design Properties:
|
Configuration Data Mapping¶
Description: JavaScript logic for loading structured JSON configuration data into form fields and collecting form data back into structured JSON format. Loading Configuration into Form: // Input: Structured JSON array from GET /api/config
async function loadConfiguration() {
try {
const response = await fetch('/api/config');
const configArray = await response.json();
// Example configArray:
// [
// {key: "wifi_ssid", type: "string", value: "MyNetwork"},
// {key: "led_count", type: "integer", value: 50},
// {key: "enable_leds", type: "boolean", value: true}
// ]
configArray.forEach(item => {
const input = document.getElementById(item.key);
if (!input) return; // Field not in form (schema mismatch)
switch(item.type) {
case 'string':
case 'integer':
input.value = item.value;
break;
case 'boolean':
input.checked = item.value;
break;
}
});
showMessage('Configuration loaded', 'success');
} catch (error) {
showMessage('Failed to load configuration: ' + error.message, 'error');
}
}
Collecting Form Data into Structured JSON: function collectFormData(schema) {
const configArray = [];
schema.fields.forEach(field => {
const input = document.getElementById(field.key);
if (!input) return;
let value;
switch(field.type) {
case 'string':
value = input.value;
break;
case 'integer':
value = parseInt(input.value, 10);
break;
case 'boolean':
value = input.checked;
break;
}
configArray.push({
key: field.key,
type: field.type,
value: value
});
});
return configArray;
}
Save Configuration to Server: async function saveConfiguration() {
try {
// Validate form first
const form = document.getElementById('config-form');
if (!form.checkValidity()) {
form.reportValidity();
return;
}
// Collect form data as structured JSON
const configArray = collectFormData(cachedSchema);
// POST to server
const response = await fetch('/api/config', {
method: 'POST',
headers: {
'Content-Type': 'application/json'
},
body: JSON.stringify(configArray)
});
if (!response.ok) {
throw new Error('Server returned ' + response.status);
}
showMessage('Configuration saved successfully', 'success');
showResetCountdown();
} catch (error) {
showMessage('Failed to save configuration: ' + error.message, 'error');
}
}
Design Properties:
|
User Interface States¶
Description: JavaScript state management for different UI states during page lifecycle. State Definitions:
State Transition Logic: let currentState = 'LOADING';
function setState(newState) {
currentState = newState;
// Update UI based on state
const form = document.getElementById('config-form');
const saveBtn = document.getElementById('save-btn');
const restoreBtn = document.getElementById('restore-btn');
const resetBtn = document.getElementById('factory-reset-btn');
const spinner = document.getElementById('loading-spinner');
switch(newState) {
case 'LOADING':
form.style.display = 'none';
spinner.style.display = 'block';
saveBtn.disabled = true;
restoreBtn.disabled = true;
resetBtn.disabled = true;
break;
case 'READY':
form.style.display = 'block';
spinner.style.display = 'none';
saveBtn.disabled = false;
restoreBtn.disabled = false;
resetBtn.disabled = false;
break;
case 'SAVING':
saveBtn.disabled = true;
saveBtn.innerHTML = '<span class="spinner"></span> Saving...';
restoreBtn.disabled = true;
resetBtn.disabled = true;
break;
case 'ERROR':
form.style.display = 'block';
spinner.style.display = 'none';
saveBtn.disabled = false;
restoreBtn.disabled = false;
resetBtn.disabled = false;
break;
case 'COUNTDOWN':
showModal('countdown-modal');
saveBtn.disabled = true;
restoreBtn.disabled = true;
resetBtn.disabled = true;
break;
}
}
|
Reset Countdown Modal¶
Description: Modal dialog with countdown timer shown after configuration save or factory reset to inform user of pending device reboot. Modal HTML Structure: <div id="countdown-modal" class="modal">
<div class="modal-content">
<h2>Configuration Saved</h2>
<p>Device will restart in <span id="countdown">5</span> seconds...</p>
<p class="warning">Page will reload automatically after restart.</p>
</div>
</div>
Countdown JavaScript Logic: function showResetCountdown(seconds = 5) {
setState('COUNTDOWN');
const countdownEl = document.getElementById('countdown');
let remaining = seconds;
const interval = setInterval(() => {
remaining--;
countdownEl.textContent = remaining;
if (remaining <= 0) {
clearInterval(interval);
// Device should have rebooted, attempt page reload
window.location.reload();
}
}, 1000);
}
Factory Reset Countdown Variant: async function factoryReset() {
// Show confirmation dialog
const confirmed = confirm(
'Factory Reset will restore all settings to defaults.\n\n' +
'WiFi credentials will be erased.\n' +
'Device will restart in AP mode.\n\n' +
'Are you sure?'
);
if (!confirmed) return;
try {
const response = await fetch('/api/config/reset', {
method: 'POST'
});
if (!response.ok) {
throw new Error('Reset failed: ' + response.status);
}
// Show countdown modal
showFactoryResetCountdown(5);
} catch (error) {
showMessage('Factory reset failed: ' + error.message, 'error');
}
}
function showFactoryResetCountdown(seconds = 5) {
setState('COUNTDOWN');
// Update modal text for factory reset
const modal = document.getElementById('countdown-modal');
modal.querySelector('h2').textContent = 'Factory Reset Initiated';
modal.querySelector('.warning').textContent =
'Device resetting to defaults. Redirecting to WiFi setup...';
const countdownEl = document.getElementById('countdown');
let remaining = seconds;
const interval = setInterval(() => {
remaining--;
countdownEl.textContent = remaining;
if (remaining <= 0) {
clearInterval(interval);
// Redirect to WiFi setup page (device now in AP mode)
window.location.href = '/wifi-setup.html';
}
}, 1000);
}
Design Properties:
|
Error Handling¶
Description: Comprehensive error handling for all API operations with user-friendly feedback. Error Categories:
Error Handling Implementation: async function apiCall(url, options = {}) {
try {
const response = await fetch(url, {
...options,
timeout: 10000 // 10 second timeout
});
if (!response.ok) {
// HTTP error
let errorMsg = `HTTP ${response.status}`;
// Try to parse error response
try {
const errorData = await response.json();
if (errorData.error) {
errorMsg = errorData.error;
}
} catch (e) {
// Response not JSON, use default message
}
throw new Error(errorMsg);
}
// Parse successful response
const data = await response.json();
return data;
} catch (error) {
// Network error or other exception
if (error.name === 'AbortError') {
throw new Error('Request timeout - device may be offline');
}
throw error;
}
}
User Feedback Display: function showMessage(message, type = 'info') {
const messageEl = document.getElementById('message-banner');
messageEl.textContent = message;
messageEl.className = `message ${type}`; // 'success', 'error', 'warning', 'info'
messageEl.style.display = 'block';
// Auto-hide success messages after 5 seconds
if (type === 'success') {
setTimeout(() => {
messageEl.style.display = 'none';
}, 5000);
}
}
Retry Logic for Critical Operations: async function loadSchemaWithRetry(maxRetries = 3) {
let lastError;
for (let i = 0; i < maxRetries; i++) {
try {
const schema = await apiCall('/api/config/schema');
return schema;
} catch (error) {
lastError = error;
if (i < maxRetries - 1) {
// Wait before retry: 1s, 2s, 4s
await sleep(1000 * Math.pow(2, i));
}
}
}
throw new Error(`Failed to load schema after ${maxRetries} attempts: ${lastError.message}`);
}
|
Page Initialization Sequence¶
Description: Complete initialization sequence when configuration page loads. Initialization Code: // Global cached schema
let cachedSchema = null;
// DOMContentLoaded event handler
document.addEventListener('DOMContentLoaded', async function() {
try {
setState('LOADING');
// Step 1: Load JSON schema with retry
showMessage('Loading configuration schema...', 'info');
cachedSchema = await loadSchemaWithRetry(3);
// Step 2: Generate form from schema
showMessage('Generating form...', 'info');
generateForm(cachedSchema);
// Step 3: Load current configuration
showMessage('Loading current configuration...', 'info');
await loadConfiguration();
// Step 4: Attach event handlers
document.getElementById('save-btn').addEventListener('click', saveConfiguration);
document.getElementById('restore-btn').addEventListener('click', loadConfiguration);
document.getElementById('factory-reset-btn').addEventListener('click', factoryReset);
// Step 5: Ready for user interaction
setState('READY');
showMessage('Configuration loaded successfully', 'success');
} catch (error) {
setState('ERROR');
showMessage('Failed to initialize page: ' + error.message, 'error');
// Show retry button
const retryBtn = document.getElementById('retry-btn');
retryBtn.style.display = 'block';
retryBtn.addEventListener('click', () => {
window.location.reload();
});
}
});
Initialization Sequence Diagram: Page Load
↓
DOMContentLoaded event
↓
setState('LOADING')
↓
Fetch /api/config/schema (with retry)
↓
Parse schema → cachedSchema
↓
generateForm(cachedSchema)
↓
Fetch /api/config
↓
Parse config array → Update form fields
↓
Attach button event handlers
↓
setState('READY')
↓
User can interact
|
Traceability¶
ID |
Title |
Status |
|---|---|---|
Configuration Webpage Architecture |
open |
|
Device Reset Countdown Interface |
open |
|
Error Handling and User Feedback |
open |
|
Configuration Data Flow |
open |
|
Dynamic Form Generation from Schema |
open |
|
Complete Page Initialization Flow |
open |
|
JSON Array to Form Field Mapping |
open |
|
UI State Management |
open |
SPEC_CFG_WEB_ARCH_1¶
